High-Definition Multimedia Interface (HDMI) cables are a must-have component of modern home entertainment systems, connecting devices such as TVs, soundbars, gaming consoles, and Blu-ray players to deliver high-quality audio and video. Among the many features HDMI offers, Audio Return Channel (ARC) and Enhanced Audio Return Channel (eARC) stand out for simplifying audio connections. These technologies allow audio to be sent from your TV to a sound system using a single HDMI cable, reducing cable clutter and enhancing user experience.

Do you know the difference between ARC and eARC? This guide helps you explore and decide which is best for your home theater setup.

What is HDMI ARC?

HDMI ARC, introduced in 2009 with the HDMI 1.4 standard, is a feature that allows audio to be sent from a TV back to a compatible sound system, such as a soundbar or AV receiver, using the same HDMI cable that carries video signals. This eliminates the need for separate optical or coaxial audio cables, streamlining setup.

How ARC Works

ARC requires both the TV and the sound system to have dedicated ARC-compatible HDMI ports, typically labeled "HDMI ARC." When connected, the TV can send audio from its built-in apps (like Netflix or YouTube) or external devices (like a Blu-ray player) to the sound system. ARC also supports Consumer Electronics Control (CEC), allowing you to control multiple devices with a single remote, such as adjusting the volume of your soundbar using your TV remote.

Supported Audio Formats

ARC supports compressed audio formats, including:

Dolby Digital

DTS

Dolby Digital Plus (used for compressed Dolby Atmos in streaming services like Netflix)

However, ARC's limited bandwidth cannot handle high-bitrate, lossless audio formats like Dolby TrueHD or DTS-HD Master Audio, nor uncompressed Dolby Atmos from Blu-ray discs.

What is HDMI eARC?

Enhanced Audio Return Channel (eARC), introduced in 2017 with HDMI 2.1, is an advanced version of ARC designed to support higher-quality audio formats. eARC offers significantly greater bandwidth, enabling the transmission of uncompressed, high-bitrate audio for a superior listening experience.

Key Improvements

eARC supports up to 32 audio channels at 24-bit/192kHz, with a bandwidth of up to 38Mbps, compared to ARC's more limited capabilities. This allows eARC to handle advanced audio formats, including:

Dolby TrueHD

DTS-HD Master Audio

Dolby Atmos (uncompressed, ideal for Blu-ray)

DTS:X

Requirements

To use eARC, both your TV and sound system must have eARC-compatible HDMI ports, typically found on devices supporting HDMI 2.1. Additionally, while some older HDMI cables may work, certified Ultra High-Speed HDMI cables (HDMI 2.1) are recommended to ensure full functionality.

Key Differences Between ARC and eARC

The following table summarizes the main differences between ARC and eARC, based on information from What Hi-Fi? and Cable Matters:

Bandwidth

ARC's limited bandwidth restricts it to compressed audio formats, making it unsuitable for high-bitrate, lossless audio. eARC's higher bandwidth supports advanced formats, delivering richer, more immersive sound.

Audio Format Support

While ARC handles basic surround sound formats like Dolby Digital and DTS, it cannot support lossless formats or object-based audio like Dolby Atmos from Blu-ray. eARC supports these advanced formats, making it ideal for audiophiles and home theater enthusiasts.

Cable Requirements

ARC works with any standard HDMI cable (HDMI 1.4 or newer). eARC, however, may require High-Speed HDMI cables with Ethernet or, preferably, Ultra High-Speed HDMI cables to ensure sufficient bandwidth for high-bitrate audio.

Compatibility

eARC is backward compatible with ARC, meaning an eARC-enabled TV can connect to an ARC-only soundbar, but you'll be limited to ARC's capabilities. To fully utilize eARC, both devices must support it.

Do You Need eARC?

Whether you need eARC depends on your home theater setup and audio preferences:

ARC is sufficient if:

You primarily stream content from services like Netflix, Disney+, or Amazon Prime Video, which use compressed Dolby Atmos via Dolby Digital Plus.

Your sound system doesn't support advanced formats like Dolby TrueHD or DTS:X.

eARC is recommended if:

You own or plan to invest in a sound system that supports uncompressed Dolby Atmos or DTS: X, especially for Blu-ray or high-end gaming.

Your TV supports eARC, and you want to future-proof your setup for higher audio quality.

You're an audiophile seeking the best possible sound experience.

HDMI Cables for ARC and eARC

For ARC: Any standard HDMI cable (HDMI 1.4 or newer) will suffice, as ARC's bandwidth requirements are modest.

For eARC: While some High-Speed HDMI cables with Ethernet may work, certified Ultra High-Speed HDMI cables (HDMI 2.1) are recommended to guarantee compatibility with eARC's higher bandwidth needs. These cables are also future-proof for 8K video and other HDMI 2.1 features. Always look for cables labeled with “HDMI” certification on the packaging.

Setting Up ARC or eARC

Setting up ARC or eARC is straightforward:

Locate the Ports: Identify the HDMI ARC or eARC port on your TV and sound system, typically labeled “HDMI ARC” or “HDMI eARC.”

Connect the Cable: Use an appropriate HDMI cable to connect the ARC/eARC ports on both devices.

Enable ARC/eARC: Access your TV and sound system's settings menu to enable ARC or eARC functionality. This may involve turning on HDMI-CEC as well.

Test the Connection: Play audio from your TV (e.g., a streaming app or connected device) to ensure the sound is output through your sound system.

If you encounter issues, ensure the correct ports are used, the cable is properly connected, and both devices have ARC/eARC enabled.

FAQs

Can I use eARC with an older soundbar?

If your soundbar only supports ARC, you can connect it to an eARC port on your TV, but you'll be limited to ARC's capabilities, missing out on eARC's advanced audio formats.

Do I need a new HDMI cable for eARC?

While some older High-Speed HDMI cables with Ethernet may work, a certified Ultra High-Speed HDMI 2.1 cable is recommended to ensure full eARC functionality and future compatibility.

Is eARC only for 4K TVs?

No, eARC is a feature of HDMI 2.1 and is focused on audio enhancement, not video resolution. It's available on many 4K and 8K TVs but benefits any setup with compatible audio devices.
